Maple Camp A 720
720 Maximum comfort on long journeys
The A 720 alcove is the largest model in its class and offers plenty of space for the whole crew with two spacious double beds - one in the alcove above the driver's cabin and one in the rear. Whether family, friends or couples with high comfort requirements: everyone will find their sleeping area here. The open-plan living area with bright furnishings, fully equipped kitchen and practical bathroom ensures a relaxed stay on the road. For additional sleeping space, the A 720 can be extended with an optional dinette bed. Thanks to the Renault Master chassis, robust full GRP body and modern insulation, you can travel comfortably and safely at any time of year.
Vehicle data
* Optional with additional dinette seats
* Optional with additional dinette bed
Interior view
That is what makes an alcove
The alcove above the cab gives this design its name. It creates an additional bed for two people there, completely without any evening conversion – ideal for children or guests. This leaves more free space downstairs: while people are already sleeping in the alcove, the seating area, kitchen, and bathroom can continue to be used, and another comfortable bed is ready for the night in the rear.
A clear plus, especially for families: more sleeping spaces on multiple levels – with full living comfort.
Technical data
Chassis Renault Master
Displacement [ccm]: 1.997
kW/hp: 96/130 (S), 110/150 (O), 125/170 (O)
Wheelbase [mm]: 4.213
Diesel tank 80 l
AdBlue tank: 20 l
Seating capacity (homologated): up to 4 (S) + 2 (O)
Overall length outside (cm): 720
Total width outside / inside (cm): 232 / 218
Total height outside / inside (cm): 314 / 210
Mass in running order (approx. kg): 3.034 (3.186 - 2.882)
Permissible total mass (kg): 3500 (S) - 4000 (O)
Manufacturer-determined mass for optional equipment [kg]: 140
Permissible trailer load braked / unbraked (kg): 2.000 / 750
Width of entrance door [cm]: 99
Garage dimensions (W x H x L) [cm]: 218x125x145
Garage flap right / left (L x W) [cm]: 70x110 / 75 x 80
Sleeping places: 4 (S) + 2 (O)
Rear double bed (L x W) (cm): 210x140
Alcove bed (L x W) (cm): 211x147
Dinette bed [cm]: 170x100 (O)
Freshwater tank capacity: 90 + 20 l
Wastewater tank capacity: 80 l
Absorption refrigerator: 136 l Thetford
Herd 2-Burner Piezo CAN
Heating: Truma Combi 4 Gas, 4 kW
WC: Thetford 18 l
Bathroom roof hatch (L x W) [cm]: 28x28
Sockets 12 V / 230 V: 1 / 2+2 (O)
USB + USB-C combo wall outlets: 3
ISOFIX child safety seat mount: 2 (O)
Floor and ceiling insulation: XPS
Wall insulation: EPS
Thickness Floor/Side walls/Roof [mm]: 42 / 34 / 34
Battery assembly: AGM 95 Ah (P)
Charger: 22 A
Renault Master, 2.0-liter dCi common-rail turbodiesel with 130 hp, 350 Nm, and 6-speed manual transmission
Safety Pack with Intelligent Speed Assistance (ISA), traffic sign recognition, speed warning system, active emergency braking system with pedestrian and cyclist detection, lane keeping assist, drowsiness and attention warning system, rear-view camera, e-Call emergency call system, and tire pressure monitoring system.
Electronic Stability Control (ESC)
Driver and front passenger airbag
Eco mode with start-stop system
Swiveling cab seats, each with two height-adjustable armrests (depending on the model)
Height and depth-adjustable multifunction steering wheel
Electrically adjustable and heated exterior mirrors
Power windows
Central locking in the cab, side and rear doors
Height-adjustable seat belts for driver and front passenger
trip computer
LED daytime running light
Radio key for central locking, low beam and cockpit lighting
Blackout curtain in the cab
Steel rims, 16 inch
GRP construction on roof, side walls, rear and underbody
XPS insulation in floor and roof
EPS insulation in the sidewalls with wood-free underbody
XL habitation door (60 cm) with window
Coupe entry with easy-entry function
Heated, illuminated, and lockable rear garage with a non-slip floor (depending on the model)
Rear garage payload up to 150 kg (depending on model)
Garage doors with a dual locking system and a unified control unit
Lashing eyes for load securing in the garage (model-dependent)
Gas cylinder cabinet for 2 x 11kg propane gas cylinders
Framed window (Dometic Seitz)
Frame extension (Sawiko) (depending on model)
LED rear lights including third brake light
External power connection and water filler neck
ABS plastic side skirts
7-year leak-proof guarantee
LED ambient lighting concept
High-quality "Moon" fabric design in light gray
Remis blackout blinds and insect screens on all windows
Roof vents (Dometic) with blackout blind and mosquito net
Optimized furniture construction for reduced condensate formation and improved air and heat circulation
Ergonomic mattresses with a breathable stretch cover (removable and washable)
Slatted frames including fall protection net
Conversion of single bed to double bed (model-dependent)
Table with sliding and rotating table top (depending on model)
Expandable dinette with T-piece and additional cushion (depending on the model)
Height-adjustable and removable headrests in the seating area
Design panels in the living and sleeping areas
Window cladding frames in living room design in kitchen and dinette
Removable dinette cushions with zipper
Pull-out clothes rail under the single bed (model-dependent)
shoe compartment in the entryway
Grab handle in the entryway
Living room mirror (model-dependent)
2- to 3-burner gas hob (CAN) with piezo ignition
Automatic absorption refrigerator (Thetford)
Stove and sink cover for work surface expansion
Drawers with soft-close function
Wall cabinets with soft-close hinges and push-lock latches
Cassette toilet (Thetford) with removable tank
Variobad (depending on model)
Shower, washbasin, mirror as well as practical cabinet and shelf space
Roof hatch for ventilation
Gas heater (Truma Combi 4) with air vents in the living area, cab, and bathroom (garage heating depending on the model)
Digital heating control panel (Truma CP+) with timer
Internal fresh water tank with electric submersible pump
Wastewater tank with external ventilation and traps in all drain pipes for odor reduction
Central operating and control panel (CBE) for controlling and monitoring vehicle functions
12V, USB, and USB-C sockets in the living area
Automatic battery charger with 22 A charging capacity
Easily accessible RCD / fuse box
Easily accessible gas shut-off valves
(S) = Standard
(O) = Optionally bookable
(P) = Package
Highlights
New Features of the 2027 Ahorn Camp Model Generation
Safety Pack incl. GSR II as standard
- Intelligent Speed Assistance (ISA) with traffic sign recognition and speed warning system
- Active Emergency Brake Assist with pedestrian / cyclist detection
- Lane departure warning
- Fatigue and attention warning
- Rear view camera
- eCall emergency call system
- tire pressure monitoring system
Smart control system
Available as an option: The CBE smart control system. All important vehicle functions at a glance:
- Display of starter and auxiliary battery voltage
- Control of indoor and outdoor lighting
- Water tank levels
- Indoor and outdoor temperature
- Water pump control
Upgrade Option: Connectivity Pack
- Router and 5G/LTE/Wi-Fi antenna for in-vehicle internet and remote access via mobile phone
- CBE Gateway with GPS function and app connectivity
- Truma CI-BUS interface for integrating heating and air conditioning systems
XPS insulation
Waterproof XPS insulation in the floor and roof protects against moisture. The pressure-resistant material impresses with high insulation performance and dimensional stability.
You might also like these models
Exterior and interior views of all models may differ from the actual view and are subject to change. Errors excepted.
